Product Description
The 65kW Air Cooled Modular Chiller is a high-efficiency cooling solution manufactured by leading Chinese durable Air Cooled Modular Chiller factory specialists. Designed for commercial and industrial applications, this chiller features an advanced modular system that allows free combination of up to 32 units in parallel, ensuring flexible installation and scalable cooling capacity. With its high-efficiency heat exchanger and R410a refrigerant, it minimizes energy loss while reducing environmental impact. The Chinese durable Air Cooled Modular Chiller factory ensures each unit is built for longevity, with components that evenly distribute running time to extend service life.
For businesses seeking reliable and adaptable cooling systems, this Chinese durable Air Cooled Modular Chiller factory product delivers exceptional performance in various environments. Its robust construction and intelligent design make it ideal for data centers, manufacturing facilities, and large commercial spaces. The modular approach not only enhances efficiency but also simplifies maintenance, ensuring consistent operation with minimal downtime.
Product Description
Modular Air Cooled Chiller
● Evenly distribute running time and increase service life.
● Use R410a refrigerant to reduce environmental pollution.
● High efficiency heat exchanger greatly reduce the energy loss.
● Modular design, flexible installation.
● Free combination up to 32 units can be connected in parallel.
Technical parameters
| Model | CLS-F65HW/ZR1B | CLS-F130HW/ZR1B | CLS-F260HW/ZR1B | ||
| Power supply | V/Ph/Hz | 380-415V/3N/50Hz | 380-415V/3N/50Hz | 380-415V/3N/50Hz | |
| Capacity | |||||
| Cooling | KW | 65 | 130 | 260 | |
| Heating | KW | 70 | 132 | 262 | |
| Electrical data | |||||
| Power input | Cooling | kW | 20.6 | 39.8 | 78.3 |
| EER | 3.16 | 3.26 | 3.19 | ||
| SEER | 3.86 | 3.95 | 3.95 | ||
| Heating | kW | 21.3 | 40.8 | 80 | |
| COP | 3.28 | 3.23 | 3.38 | ||
| SCOP | 3.51 | 3.48 | 3.48 | ||
| Physical data | |||||
| Refrigerant | Weight | kg | 13.5 | 30 | 60 |
| Refrigerant control | EXV | EXV | EXV | ||
| Type | R410A | R410A | R410A | ||
| Compressor | Type | Scroll | Scroll | Scroll | |
| oil charge | kg | 3.252*2 | 3.252*4 | 3.252*8 | |
| Quantity | PCS | 2 | 4 | 8 | |
| Dimension | Net | mm | 2000*1920*900 | 2200*2220*1100 | 3800×2130×2000 |
| (W×H×D) | Packing | mm | 2080*2060*950 | 2280*2360*1140 | 3900×2200×2100 |
| Weight | Net | kg | 610 | 1010 | 2450 |
| Gross | kg | 630 | 1060 | 2600 | |
Product Lineup
|
Power supply |
 |
 |
 |
|
380v/3ph/50hz |
65KW |
130KW |
260KW |
Application Description
Widely used in industrial and civil construction projects
Places with high requirements for operating noise and surrounding environment, water shortage or inconvenience to install cooling towers. It is especially suitable for various buildings such as hotels, restaurants, supermarkets, shopping malls, office buildings, theaters, factories, etc. It contributes to the energy saving and emission reduction of urban buildings, and becomes an ideal choice for urban building air conditioning solution.
Factory Description
Tongxing Air Conditioning Technology Co.,Ltd. is a professional heating and air conditioning system manufacturer and supplier in China, was established in 2004. We are committed to providing sustainable eco-friendly heating and air-conditioning solutions, as well as designing, installation and maintenance.
We works with leading HVAC brands, such as Gree, Midea, Carrier, and Haier at present, products covering various series like VRF, water chiller, heat pump, light commercial AC, etc.
And at same time, we have our own factory located in Jiangsu province, and our own brand:
TX, mainly produce air cooled scroll chiller, screw chiller, heat pump, dehumidifier, AHU, fan coil unit, etc, with ISO9001\ISO14001\GB/T28001.
Our Advantages
1. Combination of Design, Sales, Installation and Maintenance
2. High quality product and good price.
3. Good Pre-sale、on sale and after sales service.
4. Exported all over the world, with rich experience.
